TECHNICAL SPECIFICATIONS OF ELECTRO-VOICE EVOLVE 30M
Evolve 30M column speaker system includes array column speakers, two connecting bars, subwoofer and carrying bag for easy storage and transportation. The Evolve 30M loudspeaker is designed for intuitive assembly to meet the demands of highly portable and weather-resistant performance.
For events like weddings, the Evolve 30M mixer connects to every microphone and various input channels for guests and musicians, providing background music throughout the day while still having enough power to fill the dance floor. with DJ or live performance in the evening.
Electro-Voice Evolve 30M Array column speakers feature 6 compact 2.8" Neodymium drivers, capable of extremely wide sound coverage of 120° horizontally and 40° vertically through waveguide design and irregular design. Symmetrical for sound to spread to every position of the listener. The speaker frame is made from durable composite material combined with an aluminum handle design for easy assembly and movement. The back of the Evolve column speaker The 30M has 4 exhaust ports to help optimize acoustics and create ventilation for the speaker.
The Electro-Voice Evolve 30M subwoofer is equipped with a 10" speaker protected by a 15 mm thick wooden frame with a layered air vent design to enhance rigidity and sound performance. The Subwoofer and column array speaker are linked together to form a portable speaker system through 2 symmetrical aluminum pole connection bars with integrated internal cables and magnetic latch support. The advanced Class-D amplifier provides up to 1000 W of power, of which 500 W for the subwoofer and 500 W for the column speakers. The entire speaker system is protected by a black powder-coated 18-gauge steel grille creating an impressive design that is proportional to its outstanding audio performance.
The QuickSmart DSP processor built into the back of the sub allows you to navigate system parameters via the LCD display and control knob as well as multiple options for signal routing and input sources. QuickSmart DSP is integrated with a number of features such as 4 available performance modes (Music, Live, Speech, Club), 3-band EQ system (low, mid, high), 7-mode graphic EQ (in mode Mixer), 5 user-programmable presets allow you to set your own, store and recall quickly, Phantom power, visual monitoring of limiter status, input level and volume control key to optimizing the gain structure.
Control all speaker functions easily and conveniently via the QuickSmart Mobile app using Bluetooth Low Energy (BTLE) technology allowing you to wirelessly configure, control and monitor all parameters of six Evolve 30M systems at the same time via smart device. The Evolve 30M column speaker system is as simple or complex as your application, producing great sound with ease for users of all levels.
In collaboration with the world-class audio engineering team at Dynacord, the Electro-Voice Evolve 30M digital mixer features a fully programmable, configurable eight-channel digital mixer. with multiple inputs (4 XLR/TRS combo microphone/line inputs, 1 XLR/TRS combo stereo input, 1 RCA headphone jack, 1 3.5mm input, 1 Hi-Z instrument input and into wireless Bluetooth® audio) with professional audio mixing and preamplification. The mixer can be controlled via the QuickSmart Mobile app or via an LCD interface combined with a control knob.
Integrated AUX outputs, Hi-Z inputs, and effects switching inputs provide flexible configuration along with a suite of studio-quality audio effects (30 available, including chorus, delay, flange and reverb, via two FX channels), providing endless options for sound manipulation. Along with the integrated mixer, the Evolve 30M speakers help users minimize installation time as well as the need for separate mixing desks or effects pedals, making the stage setup/cleanup process quick and easy. easier.
***LISTED PRICE IS FOR 1 SPEAKER.
CONTACT US, WE OFFER 24/7 CUSTOMER SERVICE!!!
Specification
Coverage (H x V) | 120° x 40° |
Amplifier rating | 1000 W |
LF channel rating | 500 W |
HF channel rating | 500 W |
Crossover frequency | 200 Hz |
Connectors | 4x XLR/TRS Combo Jack Line / Mic Input |
1x 1/4" TRS HI-Z input | |
2x XLR/TRS Combo Jack for Stereo Line Input | |
1x Stereo RCA Input | |
1x 3.5 mm Stereo Input | |
1x Wireless Stereo Bluetooth® Audio Input | |
1x 1/4" Foot Switch Input | |
1x XLR MIX OUT Output | |
1x XLR AUX OUT Output | |
Enclosure | Sub: 15 mm plywood |
Column: Composite | |
Pole: Aluminum | |
Grille: Steel with black or white powder coat | |
Color: | Black or white |
Dimensions (HxWxD): mm (in) | Sub: 448 x 332 x 432 (17.6 x 13.1 x 17) |
Column: 620 x 95 x 157 (24.4 x 3.7 x 6.2) | |
Pole (2 pcs): 600 x 48 x 55 (23.6 x 1.9 x 2.2) | |
Net weight | Sub: 34.9 lb (15.8 kg) |
Column: 6.0 lb (2.7 kg) | |
Pole (2 pcs): 3.1 lb (1.4 kg) | |
Bag for column and pole: 1.9 (0.85 kg) | |
Shipping weight | 53.4 lb (24.2 kg) |
Power consumption3 | 100-240 V AC, 50-60 Hz, 1.5-0.6 A |
